Material clip profile spiral: hot-dip galvanised steel band wall: inner PTFE foil, electroconductive, outer layer: HYPALON®-coated polyester fabric Applications ● Danger zones, which require electro- ● Phamaceutical industry ● Chemicals ● Low pressure range ● Suction and conveyance of aggressive ● Paint, wood and paper industry ● Solvent extraction | Properties ● smallest bending radii ● highly flexible ● UV/ozone-proof ● vibration-proof ● excellent chemical resistance ● cold and heat-resistant ● weather-proof ● optimum medium flow characteristics ● outer chafing protection spiral ●high tension-proof connection of wall-lining and spiral via special clamp mechanism●adheres to TRBS 2153 (Zone 0/20) for flammable dusts and gases with lowconductivity for dissipation of electrostatic charges with double-ended grounding ● PTFE-Folie: surface resistance R O < 10 ● extremely compressable to approx. 1:4 ● robust outer wall material ● anti-adhesive internal wall lining material Temperature Range ● -40°C to +175°C ● peaks to +190°C |
